Old 10-22-2019, 12:31 PM   #1
Veteran Member

City: Corpus Christi
Country: USA
Vessel Name: Sunrise
Vessel Model: Gemini 105mc
Join Date: Oct 2014
Posts: 52
Send a message via Skype™ to The Brockerts
Hinged Electrical Panels ?

I've search for info on the electrical panel setup on my new to me 1990 Californian but didn't find what I as looking for. So before I do something I'll regret I'll ask. See the AC panel below, it has a hinge at the bottom. So besides the standard of disconnect from shore power, make sure the generator is not running, I should then be able to unscrew the top and sides of the panel and lay it down to service it in a safe manner?, Seems to easy, anything else I should know? Does it close back up easily ?

The plan is to connect up an inverter properly. The DC power was connected to the starter lug on the generator. Probably not the best idea. The AC side was just some outlet around the boat.

I'm still not sure exactly how I'm setting it up, but the forum has some great suggestions.
and of course the picture is sideways, going to have to figure out the EXIF setting

The Brockerts
Attached Thumbnails
Click image for larger version

Name:	PanelACside.jpg
Views:	39
Size:	138.5 KB
ID:	95573
__________________
Advertisement

The Brockerts is offline   Reply With Quote
Old 10-22-2019, 12:57 PM   #2
Guru

Comodave's Avatar

City: Au Gres, MI
Country: US
Vessel Name: Never Say Never
Vessel Model: President 41 DC
Join Date: Jul 2015
Posts: 5,776
I would also kill the DC power to the panel before opening it the first time until you know that nothing will short out or pull loose. I like hinged panels because it is easy to service them. I replaced my main electrical panel a couple of years ago and hinged it on the side so it swings out. I built a small, about 4Ē deep cabinet to house the new panel since the new panel is horizontal and the old panel was vertical.
Attached Thumbnails
Click image for larger version

Name:	C822E653-AF43-4A08-A37C-E201D39A3655.jpg
Views:	38
Size:	160.5 KB
ID:	95574   Click image for larger version

Name:	8424846B-CEEE-48CC-9B64-5B50965463B5.jpg
Views:	39
Size:	192.5 KB
ID:	95575
__________________

__________________
Boat Nut:
If you are one there is no explanation necessary.
If you arenít one, there is no explanation possible.
Comodave is offline   Reply With Quote
Old 10-22-2019, 12:59 PM   #3
Guru

City: Fairport
Country: United States
Join Date: Jan 2017
Posts: 1,686
I like bottom side piano hinged panels. When I did mine, you do need to make sure the cables are bundled to exit the panel at the hinge end. THey will twist 90 degrees to allow the panel to rotate away from the bulkhead.
Also, you might (I did) need some support lines running from the top of the panel to the bulkhead. These limit travel, so you don't need to support the open panel. These supports should be non-conductive, for hopefully obvious reasons.
diver dave is offline   Reply With Quote
Old 10-22-2019, 01:06 PM   #4
Guru

Comodave's Avatar

City: Au Gres, MI
Country: US
Vessel Name: Never Say Never
Vessel Model: President 41 DC
Join Date: Jul 2015
Posts: 5,776
I actually prefer the hinge on the side. That way when you open the panel you donít have to reach in over the panel to work inside the cabinet. I swing mine open and I can sit in the opening and work inside. I have all the wiring crossing over to the panel down on the hinge side with enough slack to swing open. I have a bunge that pulls up on the wiring as the panel swings closed so the wiring moves up out of the way.
__________________
Boat Nut:
If you are one there is no explanation necessary.
If you arenít one, there is no explanation possible.
Comodave is offline   Reply With Quote
Old 10-22-2019, 01:10 PM   #5
Guru

City: Fairport
Country: United States
Join Date: Jan 2017
Posts: 1,686
Proceed with caution with side opening panels on a boat that contain hazardous voltages. In industry, they would have to be "touch safe". On a boat, it is even more risk, since the boat can rock, sometimes unexpectedly.
Lots of touch proof terminals and connectors out there, but few vintage N America boats have them. Also, don't underestimate the power of 12 and 24V dc in a panel, if jewelry gets across them. And, that caution will apply to any hinge location.
diver dave is offline   Reply With Quote
Old 10-22-2019, 01:19 PM   #6
Guru

Comodave's Avatar

City: Au Gres, MI
Country: US
Vessel Name: Never Say Never
Vessel Model: President 41 DC
Join Date: Jul 2015
Posts: 5,776
My panel latches open. I never wear jewelry since I was a computer engineer at one time. The 120 volt side has a non conducive cover over the back.
__________________
Boat Nut:
If you are one there is no explanation necessary.
If you arenít one, there is no explanation possible.
Comodave is offline   Reply With Quote
Old 10-22-2019, 02:43 PM   #7
Guru

OldDan1943's Avatar

City: Aventura FL
Country: USA
Vessel Name: Kinja
Vessel Model: American Tug 34 #116
Join Date: Oct 2017
Posts: 4,106
There is a piano on the starboard side of my electrical panel. To hold it open, I have a genuine wooden stick. SMILE
__________________
Did Noah have a get home-engine?
OldDan1943 is offline   Reply With Quote
Old 10-22-2019, 03:46 PM   #8
Guru

City: Fairport
Country: United States
Join Date: Jan 2017
Posts: 1,686
Quote:
Originally Posted by OldDan1943 View Post
There is a piano on the starboard side of my electrical panel. ..SMILE
Your boat must be larger than it looks!
diver dave is offline   Reply With Quote
Old 10-22-2019, 04:38 PM   #9
Guru

OldDan1943's Avatar

City: Aventura FL
Country: USA
Vessel Name: Kinja
Vessel Model: American Tug 34 #116
Join Date: Oct 2017
Posts: 4,106
Quote:
Originally Posted by diver dave View Post
Your boat must be larger than it looks!
Every boat has an electrical panel
__________________
Did Noah have a get home-engine?
OldDan1943 is offline   Reply With Quote
Old 10-22-2019, 04:49 PM   #10
Ted
Guru

Ted's Avatar

City: Campbell River
Country: Canada
Vessel Name: Okisollo
Join Date: Apr 2012
Posts: 643
Yes, but I only know one boat up here with a piano, Coastal Messenger, a mission boat
Ted is offline   Reply With Quote
Old 10-22-2019, 05:08 PM   #11
Enigma

RT Firefly's Avatar

City: Slicker?
Country: Bumpkin?
Join Date: Oct 2007
Posts: 12,747
Greetings,
Mr. T. You mean Mr. OD is a missionary? I would have never guessed.


__________________
RTF
RT Firefly is online now   Reply With Quote
Old 10-22-2019, 05:14 PM   #12
Guru

OldDan1943's Avatar

City: Aventura FL
Country: USA
Vessel Name: Kinja
Vessel Model: American Tug 34 #116
Join Date: Oct 2017
Posts: 4,106
And to draw this to a conclusion, I meant a piano hinge.
LOL
__________________
Did Noah have a get home-engine?
OldDan1943 is offline   Reply With Quote
Old 10-22-2019, 05:20 PM   #13
Guru

City: Fairport
Country: United States
Join Date: Jan 2017
Posts: 1,686
Quote:
Originally Posted by OldDan1943 View Post
And to draw this to a conclusion, I meant a piano hinge.
LOL
oh no. we are not done yet. Waiting for RT to get a graphic of a baby grand in your salon.

And, what a coincidence. My mom used a wooden stick to keep her piano top open. small world.
diver dave is offline   Reply With Quote
Old 10-22-2019, 05:30 PM   #14
Enigma

RT Firefly's Avatar

City: Slicker?
Country: Bumpkin?
Join Date: Oct 2007
Posts: 12,747
Greetings,
Mr. dd. SALOON!!! I just happen to have a candid shot of Mr. OD...


__________________
RTF
RT Firefly is online now   Reply With Quote
Old 10-22-2019, 05:51 PM   #15
Guru

City: Fairport
Country: United States
Join Date: Jan 2017
Posts: 1,686
priceless;
diver dave is offline   Reply With Quote
Old 10-22-2019, 06:53 PM   #16
Guru

OldDan1943's Avatar

City: Aventura FL
Country: USA
Vessel Name: Kinja
Vessel Model: American Tug 34 #116
Join Date: Oct 2017
Posts: 4,106
Quote:
Originally Posted by RT Firefly View Post
Greetings,
Mr. dd. SALOON!!! I just happen to have a candid shot of Mr. OD...


Alas, I can not see your graphic.
__________________
Did Noah have a get home-engine?
OldDan1943 is offline   Reply With Quote
Old 10-22-2019, 07:05 PM   #17
Enigma

RT Firefly's Avatar

City: Slicker?
Country: Bumpkin?
Join Date: Oct 2007
Posts: 12,747
Greetings,
Mr. OD. It's pretty well along these lines but a bit more garish. Remember, this is a picture of YOU in your SALOON at your piano.



__________________
RTF
RT Firefly is online now   Reply With Quote
Old 10-22-2019, 07:08 PM   #18
Guru

City: Fairport
Country: United States
Join Date: Jan 2017
Posts: 1,686
Both my dell and imac accept RT graphics using chrome But no app reveals them on my iphone.
diver dave is offline   Reply With Quote
Old 10-22-2019, 07:55 PM   #19
Guru

Comodave's Avatar

City: Au Gres, MI
Country: US
Vessel Name: Never Say Never
Vessel Model: President 41 DC
Join Date: Jul 2015
Posts: 5,776
This has to be a record for thread drift...
__________________
Boat Nut:
If you are one there is no explanation necessary.
If you arenít one, there is no explanation possible.
Comodave is offline   Reply With Quote
Old 10-22-2019, 07:59 PM   #20
Guru

City: Fairport
Country: United States
Join Date: Jan 2017
Posts: 1,686
We are glad u resurfaced. We have an IT issue.
