Old 07-01-2015, 08:45 PM   #41
TF Site Team

Baker's Avatar

City: League City, Tx
Country: Texas
Vessel Model: Carver 356
Join Date: Oct 2007
Posts: 5,630
Quote:
Originally Posted by Joebad View Post
My research says both Volvo and Cummins make exceptional marine diesel engines, probably the best two out there in the sizes most of us would consider. Chessie Cummins built his first diesel around 1920 and early ones were for marine (he was a boating fanatic). I am not sure Volvo had made a diesel that long ago but that really means nothing. Cummins has now replaced the 5.9 with the new 6.7, same horsepowers, but gobs more torque, yields notably greater acceleration and just a touch more top speed. But the 6.7 is extremely quiet and has very low emissions, compared to its very popular predecessor. I don't know what Volvo has done lately but I doubt they have been sitting on their thumbs. Their engines are in very upscale boats and that tells me they are also outstanding motors. My two cents worth. My new boat will have the Cummins 6.7 made in Indiana and shipped to France to install in my boat. I would say I am prejudiced, as I am a Hoosier. But I have fond memories of a Volvo 240D station wagon I once had, nuff said!!
The Cummins QSB5.9 still exists as far as I know.... You might be hung up on their road stuff. And their power outputs are close but can be different. Volvo support is a nightmare....I don't care how good their engines might be.
__________________
Advertisement

__________________
Prairie 29...Perkins 4236...Sold
Mainship Pilot 30...Yanmar 4LHA-STP...Sold
Carver 356...T-Cummins 330B
Baker is offline   Reply With Quote
Old 07-02-2015, 11:23 AM   #42
Guru

refugio's Avatar

City: Meydenbauer Bay Yacht Club
Country: USA
Vessel Name: Refugio
Join Date: Mar 2012
Posts: 1,141
My Volvo TMD-100A is a Turbo-charged, Marine version of a Diesel...tractor engine.

It's still in use in many single engine commercial vessels throughout the world. Hatton Marine in Seattle has never had a problem getting parts, and they even have some used parts when appropriate (I needed a replacement cooling tank about 10 years ago - used was under a BU versus maybe 3 BU for NOS).

I'm a "one rat study", but I am a satisfied rat. 😀
__________________

__________________
Keith
refugio is offline   Reply With Quote
Old 07-02-2015, 11:54 AM   #43
Guru

ancora's Avatar

Join Date: Dec 2007
Posts: 3,490
I have had my VOLVO TMD40's for fifteen years and can attest to their ease of maintenance as I do all my own work on them. It just galls me that VOLVO does not care that they have the worst customer service in the industry. It doesn't have to be that way.
ancora is offline   Reply With Quote
Old 07-02-2015, 01:32 PM   #44
Guru

Nomad Willy's Avatar

City: Concrete Washington State
Country: USA
Vessel Name: Willy
Vessel Model: Willard Nomad 30'
Join Date: Oct 2007
Posts: 13,712
Richard (Wxx3) wrote;
"In addition, I was going to respond to Marin and say that to ASSUME an engine is better because it was designed for marine application is truly out of this world."

There are no engines in boats our size designed as marine engines. If there were they would have their flywheels on the front of the crankshaft instead of the back. Rear mounted flywheels on small boats aren't a feature on marine engines for small boats .. only conversions.

And if you were powering a boat most likely having a flywheel on the front is an advantage or offers several advantages. The option to mount the engine as low as possible in the boat is obvious but CG, engine mounts, transmissions and other things may enter into it. So an engine designed as a marine engine may have many advantages but it probably dosn't relate to the basic quality of the engines. Alloys used, machining methods, tolerances and quality of bolt on outsourced materials and components all contribute to quality. But if the engine is destined for a boat boat stuff counts.
__________________
Eric

North Western Washington State USA
Nomad Willy is online now   Reply With Quote
Old 07-02-2015, 01:52 PM   #45
Guru

LarryM's Avatar

City: League City, TX
Country: USA
Vessel Name: Pelago
Vessel Model: Wellcraft 3300 Coastal
Join Date: Aug 2011
Posts: 843
Quote:
Originally Posted by manyboats View Post
Richard (Wxx3) wrote;
"In addition, I was going to respond to Marin and say that to ASSUME an engine is better because it was designed for marine application is truly out of this world."

There are no engines in boats our size designed as marine engines. If there were they would have their flywheels on the front of the crankshaft instead of the back. Rear mounted flywheels on small boats aren't a feature on marine engines for small boats .. only conversions.
Eric,

Sorry, but I'm going to have to throw a flag on that statement. The Volvo MD series marine diesels were designed and built for one thing, and one thing only, boats. Granted, later small marine diesels are often based on industrial or automotive designs, but some engines are definitely marine only.

__________________
Larry
M/V Pelago
LarryM is offline   Reply With Quote
Old 07-02-2015, 01:56 PM   #46
Guru

Heron's Avatar

City: Cypress Landing Marina (NC)
Country: USA
Vessel Name: Heron (2)
Vessel Model: '88 Cape Dory 28 Flybridge #115
Join Date: Nov 2014
Posts: 1,082
Run what you got.....Some of us, in a quest for the right boat, don't have a choice...:-)

__________________
Steve
Heron is offline   Reply With Quote
Old 07-02-2015, 03:06 PM   #47
Guru

City: Venice Louisiana
Country: United States
Join Date: Dec 2013
Posts: 1,097
The electric clutch for the supercharger in later models of Vulva engines was a joke. It was just not funny. Knomes, all of those engineers were knomes.
kulas44 is offline   Reply With Quote
Old 07-02-2015, 03:19 PM   #48
Guru

Ski in NC's Avatar

City: Wilmington, NC
Country: USA
Vessel Name: Louisa
Vessel Model: Custom Built 38
Join Date: Jan 2014
Posts: 3,888
Quote:
Originally Posted by LarryM View Post
Eric,

Sorry, but I'm going to have to throw a flag on that statement. The Volvo MD series marine diesels were designed and built for one thing, and one thing only, boats. Granted, later small marine diesels are often based on industrial or automotive designs, but some engines are definitely marine only.

That might be a purpose built marine engine, but geez it is sea water cooled. I've spent a bunch of time trying to chip out corrosion blocking coolant channels on those. Most aggravating. Direct cooling is a definite cheap-out.

It does not matter if an engine is built for marine, automotive, industrial, agriculture, whatever. An engine just converts fuel and air into spin, heat, noise and smoke. Does not matter what it started life as, they all do the same thing. We just want the "spin".

What matters is the quality of the engineering that adapts the engine to the unique marine environment.

A few rules seem to apply:

NO ALUMINUM in contact with coolant. Volvo and Yanmar fail here. Lots of aluminum here like whole exhaust manifolds. So what, save 20lbs, create maintenance nightmare. Detroit, Cat and Cummins- Zero Al in contact with coolant.

No sea water oil coolers. Volvo and Yanmar again fail. Detroit, Cat and Cummins simply do not do that. Coolant cools oil, much better temp control, no corrosion issues. Oil hot enough to keep dry.

Simple serviceable coolers. Cummins uses Serck and Sen-Dure coolers, easy to service and easy to remove from engine. Cat and Yanmar similar, easy to service. Some Volvo stuff is a real PITA and since made in house, parts availability is up to them.

I can get a 30yr old Detroit cooler direct from Sen-Dure.

There are a few valid complaints about the Cummins- Stupid leaking sherwood pumps and having to pull a mount to replace. Putting the leaky pump above the HPFP on the QSB...

But in general, Cummins does a better job than just about anyone else.

I don't have much Deere experience, just not many in my fleet. Generally very good as I hear, but I think they use aluminum in coolant path too. Someone else might confirm..

Still waiting on stupid building permits. This is killing me.
Ski in NC is offline   Reply With Quote
Old 07-02-2015, 04:13 PM   #49
Guru

LarryM's Avatar

City: League City, TX
Country: USA
Vessel Name: Pelago
Vessel Model: Wellcraft 3300 Coastal
Join Date: Aug 2011
Posts: 843
Ski,

I agree on all points. Decades ago, some of the marine diesels were made specifically for the marine market. They were produced in low numbers, raw-water cooled, and designed with heavy castings to last in the marine environment. Their heavier mass allowed for smooth running, and their relatively low rpm minimized bearing wear. Many are still going strong today. I had a Volvo MD6 that ran over 30 years in salt water with no issues at all. I changed impellers when needed and replaced one mixing elbow, but never worried about the rest of the cooling system.

Now, I have a Yanmar 4JH3E that is a great engine except I worry about the aluminum heat exchanger, which although still in great shape, is a real concern as the engine ages. I change the coolant annually and even check the voltage of the coolant a couple of times a year. If they had used cast iron instead of aluminum none of this would be necessary. And according to the PO, it lost an oil cooler to corrosion at about 1,000 hr. Supposedly there was an engineering change that solved that problem, but I inspect it annually as well.

Like you, I have heard good things about Deere.
__________________
Larry
M/V Pelago
LarryM is offline   Reply With Quote
Old 07-02-2015, 07:12 PM   #50
Guru

City: Venice Louisiana
Country: United States
Join Date: Dec 2013
Posts: 1,097
Detroit Diesel marine 8v53s had aluminum heat exchangers. Not so good, so they all make mistakes. Take the Cat 3116 for example. Volvo however, seems to be very good at doing stupid things. And just keeps coming up with increasingly stupider (is that a word ?) things.
kulas44 is offline   Reply With Quote
Old 07-02-2015, 07:53 PM   #51
Guru

Nomad Willy's Avatar

City: Concrete Washington State
Country: USA
Vessel Name: Willy
Vessel Model: Willard Nomad 30'
Join Date: Oct 2007
Posts: 13,712
Quote:
Originally Posted by LarryM View Post
Eric,

Sorry, but I'm going to have to throw a flag on that statement. The Volvo MD series marine diesels were designed and built for one thing, and one thing only, boats. Granted, later small marine diesels are often based on industrial or automotive designs, but some engines are definitely marine only.

Larry I'm very glad to have been found wrong. WOW it looks indeed that you are right. That's wonderful. I remember the Albineer's Club where so many had these engines. Had no idea they were completely marine.
Another 100% marine engine is the 22hp Albin engine that powered the first Albin boats. It was designed as a marine engine and unbeliveably the 25' Albin boat was created for the engine.

There's two so there could be more. But wouldn't be surpprised if that was it.

Larry "decades ago" like about 60 years or more there were engines like Lathrop, Hercules, Redwing, Universal, Chris Craft, Nordberg, Kermath and I think even Chrysler was a true marine engine.

Ski,
I remember many tales of the MD Volvo's lasting 30+ years. Wouldn't that be a sure sign of a marine engine? Had to be built for it or they would never have lasted 30years. But re aluminum manifolds I agree. That's one of the big reasons I chose the Klassen engine for my boat.

Thank you LarryM.
__________________
Eric

North Western Washington State USA
Nomad Willy is online now   Reply With Quote
Old 07-02-2015, 10:59 PM   #52
Guru

refugio's Avatar

City: Meydenbauer Bay Yacht Club
Country: USA
Vessel Name: Refugio
Join Date: Mar 2012
Posts: 1,141
My dad's Ingrid 38 had a Sabb diesel - I think they might be marine only.

But I think a lot of this confusion is about "lightweight" diesels, which are a tremendous challenge in the marine world. I know others here are not fans of David Pascoe, but I think his rule of thumb works just fine.
__________________
Keith
refugio is offline   Reply With Quote
Old 07-03-2015, 06:27 AM   #53
FF
Guru

FF's Avatar

Join Date: Oct 2007
Posts: 16,529
Those Volvo MD 1 , 2 or 3 were probably the last marine engines Volvo made.

With the decades of rule expansion by the Air Police of the world , the number of engine Mfg has declined , so except for large ship engines , most small boats with a 50-500hp need will be using marinizations.

Happily tho the engine guys are working hard to bring mechanical injected engines up to Air Police specs.


The commercials of the world are not happy with $1000 injectors and $10,000 brain boxes.
FF is offline   Reply With Quote
Old 07-03-2015, 10:43 AM   #54
Guru

Nomad Willy's Avatar

City: Concrete Washington State
Country: USA
Vessel Name: Willy
Vessel Model: Willard Nomad 30'
Join Date: Oct 2007
Posts: 13,712
refugio,
I had a feeling another one would pop up.
I agree. I'm sure those Sabbs were 100% marine.

I don't however think "lightweight" has anything to do w it. Well one thing is obvious. The pool of diesels that get marineized are probably lighter weight as they come from applications where a light engine is more desirable. Don't want a monstrous pice of cast iron on a small tractor or in a sailboat. And of course lightweight is a good thing for non-trawler type boats. Most all the small marine diesels have aluminum manifolds. In this case lightweight is not good IMO.
__________________

__________________
Eric

North Western Washington State USA
Nomad Willy is online now   Reply With Quote
