New Shower Trick

Hi All,

My shower has learned a new trick and it's no fun

I have an '82 GB and the water temperature that comes out of the shower head pulsates back and forth between scalding hot and cold water.

I have three sinks (two heads and the galley) and this problem does not exist anywhere but the shower. I have a Jabsco Par-Max Plus water pump, but it seems to be above reproach given that this only happens in the shower.

Where do I start?

THANKS!
__________________
Advertisement

R lucky is offline   Reply With Quote
Old 12-10-2019, 12:54 AM   #2
Enigma

RT Firefly's Avatar

City: Slicker?
Country: Bumpkin?
Join Date: Oct 2007
Posts: 13,175
Greetings,
Mr. Rl. "Where do I start?" Stop taking showers.


__________________

__________________
RTF
RT Firefly is online now   Reply With Quote
Old 12-10-2019, 01:02 AM   #3
Member

City: Marina del Rey
Country: United States
Vessel Name: Fortunate Son
Vessel Model: 42' Grand Banks M/Y
Join Date: Feb 2017
Posts: 22
Nice

I don't mind being dirty, but being single is another matter...
R lucky is offline   Reply With Quote
Old 12-10-2019, 01:28 AM   #4
Guru

Comodave's Avatar

City: Au Gres, MI
Country: US
Vessel Name: Never Say Never
Vessel Model: President 41 DC
Join Date: Jul 2015
Posts: 6,347
Maybe a washer is loose and blocking the flow to one side??? Not an expert on plumbing for sure but I would take the faucet apart and look for something loose inside.
__________________
Boat Nut:
If you are one there is no explanation necessary.
If you arenít one, there is no explanation possible.
Comodave is online now   Reply With Quote
Old 12-10-2019, 01:45 AM   #5
Member

City: Marina del Rey
Country: United States
Vessel Name: Fortunate Son
Vessel Model: 42' Grand Banks M/Y
Join Date: Feb 2017
Posts: 22
Thank you

Thanks Comodave. That sounds like a reasonable possibility and I'll give it a shot.

Lucky
R lucky is offline   Reply With Quote
Old 12-10-2019, 01:49 AM   #6
Guru

City: Clearwater, FL
Country: United States
Vessel Name: Seas the Bay
Vessel Model: 1981 42' Hardin Europa
Join Date: Aug 2016
Posts: 707
Does the pulsating follow the on-and-off of the water pump. In other words, does it become scalding when the bump runs and cold when the accumulator is driving it between cycles?

I'm wondering about hot water expansion in the system or a bad accumulator or air trapped in the tank resulting in a higher hot water pressure than cold water pressure at certain times in the cycle? Does it go away or get better if a sink is left running hot water slowly?

Also, what about a leak letting air in near the shower and air daming the showers mixer or anti scale valve and then flushing out to accumulate again?

Or...as others have said a bad shower faucet or one with debris flapping around? Simpler failure mode, maybe.

-Greg
gkesden is online now   Reply With Quote
Old 12-10-2019, 02:07 AM   #7
Member

City: Marina del Rey
Country: United States
Vessel Name: Fortunate Son
Vessel Model: 42' Grand Banks M/Y
Join Date: Feb 2017
Posts: 22
Hi Greg,

Thanks. The pulsating is consistent from the time the faucets are open -- it does not follow the cycling of the water pump. Thanks for pointing out the other possibilities, I'll put them on the list.

Lucky
R lucky is offline   Reply With Quote
Old 12-10-2019, 02:26 AM   #8
Guru

City: Clearwater, FL
Country: United States
Vessel Name: Seas the Bay
Vessel Model: 1981 42' Hardin Europa
Join Date: Aug 2016
Posts: 707
Hey Lucky,

Does pressure change? For example, go down during the hot pulses? Or cold pulses? Or even go up?

Do the pulses have a consistent rhythm? Or random? What is the interval like?

Thanks,
-Greg
gkesden is online now   Reply With Quote
Old 12-10-2019, 02:28 AM   #9
Senior Member

localboy's Avatar

City: Lake Stevens, WA via Honolulu
Country: USA
Vessel Name: 'Au Kai (Ocean Traveler)
Vessel Model: C-Dory 25
Join Date: Sep 2019
Posts: 230
Quote:
Originally Posted by RT Firefly View Post
Greetings,
Mr. Rl. "Where do I start?" Stop taking showers.


Ironically, that sounds like something Groucho Marx would say...
__________________
Aloha...Mark
localboy is offline   Reply With Quote
Old 12-10-2019, 06:20 AM   #10
FF
Guru

FF's Avatar

Join Date: Oct 2007
Posts: 19,923
There should be a working check valve at the HW heater to prevent warm expanded water from going back towards the pressure pump. See if its working.
FF is offline   Reply With Quote
Old 12-10-2019, 07:11 AM   #11
Guru

O C Diver's Avatar

City: Fort Myers, FL... Summers in Crisfield, MD
Country: USA
Vessel Name: Slow Hand
Vessel Model: Cherubini Independence 45
Join Date: Dec 2010
Posts: 7,935
If it's only at the shower control, I would suspect the control itself, the plumbing just before it, or between the shower head / hand held sprayer and the control.

My inclination would be to work backwards. Start by removing the shower head / sprayer and see if the situation continues without it attached.

Ted
__________________
Blog: mvslowhand.com
I'm tired of fast moves, I've got a slow groove, on my mind.....
I want to spend some time, Not come and go in a heated rush.....
"Slow Hand" by The Pointer Sisters
O C Diver is online now   Reply With Quote
Old 12-10-2019, 07:29 AM   #12
Enigma

RT Firefly's Avatar

City: Slicker?
Country: Bumpkin?
Join Date: Oct 2007
Posts: 13,175
Greetings,
Mr. Rl. Re: Post #3. EXCELLENT answer! Thanks. You'll fit right in here. I've nothing to add to the suggestions already posted.


__________________
RTF
RT Firefly is online now   Reply With Quote
Old 12-10-2019, 08:12 AM   #13
Guru

wkearney99's Avatar

City: Bethesda, MD
Country: USA
Vessel Name: Solstice
Vessel Model: Grand Banks 47 Eastbay FB
Join Date: Feb 2018
Posts: 1,067
Quote:
Originally Posted by Comodave View Post
Maybe a washer is loose and blocking the flow to one side??? Not an expert on plumbing for sure but I would take the faucet apart and look for something loose inside.
That'd be my starting point, also. If there's something stuck in the mixing valve you might get symptoms like that. Find out what kind of mixer is installed and see if you can find the manual for it online. That would give you a head start on figuring out how to properly disassemble and service it.
__________________
-- Bill Kearney
2005 Eastbay 47 FB - Solstice
wkearney99 is offline   Reply With Quote
Old 12-10-2019, 09:38 AM   #14
TF Site Team

City: Westerly, RI
Country: USA
Vessel Name: N/A
Vessel Model: 1999 Mainship 350 Trawler
Join Date: Jan 2014
Posts: 1,953
It sounds like the mixer valve on the shower might be sucking a little bit of air. If this doesn't occur with any other faucet, then you have to discount the tank, fittings and pump all the way to the only variable where behavior is different. (theoretically).
Shrew is offline   Reply With Quote
Old 12-10-2019, 10:45 AM   #15
Guru

Alaskan Sea-Duction's Avatar

City: Inside Passage Summer/Columbia River Winter
Country: USA
Vessel Name: Alaskan Sea-Duction
Vessel Model: 1988 M/Y Camargue YachtFisher
Join Date: Jul 2012
Posts: 5,011
Quote:
Originally Posted by Shrew View Post
It sounds like the mixer valve on the shower might be sucking a little bit of air. If this doesn't occur with any other faucet, then you have to discount the tank, fittings and pump all the way to the only variable where behavior is different. (theoretically).
I would agree. Sounds like air is entering your system. Just the hot side or cold or both hot and cold? Any leaks in the system?

Try disconnecting the shower hose at the mixer. Still have the issue at the mixer valve?

No? The issue is your shower head and/or shower hose to head.


Yes, you have an issue between the mixer and the hot water heater. Check your water lines from the mixer to the hot water heater. Check cold back to the first "T"

Good luck.
Alaskan Sea-Duction is offline   Reply With Quote
Old 12-10-2019, 10:57 AM   #16
Guru

Xsbank's Avatar

City: Pender Harbour, BC
Country: Canada
Vessel Name: Gwaii Haanas
Vessel Model: Custom Aluminum 52
Join Date: Sep 2013
Posts: 3,356
Many systems have a mixing device such that the hot water is mixed with cold to make sure you don’t get scalded. Check that out?
__________________
Don't believe everything that you think.
Xsbank is offline   Reply With Quote
Old 12-10-2019, 11:22 AM   #17
Guru

syjos's Avatar

City: Gig Harbor
Country: USA
Vessel Name: Sandpiper
Vessel Model: Bluewater 40 Pilothouse Trawler
Join Date: Nov 2012
Posts: 995
Post #10 would be the first thing to check.

An accumulator would dampen pulses.

If the shower valve is a domestic unit like the first picture, it may have a pressure balance valve built into it.

A pressure-balance valve is basically a standard single-handle mixing valve with one important addition: a pressure-sensitive piston, spool or diaphragm. When the hot water pressure increases relative to the cold pressure, it moves in one direction to limit hot water flow while at the same time increasing the flow of cold water. When the cold water pressure increases, it moves in the opposite direction to limit the flow of cold water and increase the flow of hot water. The ultimate result, in either case, is that the water temperature stays the same.

If there is debris in the pressure balance valve or you don't have a check valve as described above or the valve is bad, the diaphgram could be oscillating back and forth causing the pulsation. Replacing the cartridge may fix the issue.

Pressure balancing valves does not work as well on boat water systems with pulsating pumps, inconsistent pressure and slow temperature rise marine water heaters.

Install a true thermostat controlled shower valve like the Grohe Grotherm - second picture. That's what I have in Sandpiper and my wife can wash dishes while I shower with no temperature swings.
Attached Thumbnails
Click image for larger version

Name:	chrome-with-valve-moen-mixing-valves-t2151-2520-64_1000.jpg
Views:	44
Size:	56.2 KB
ID:	97416   Click image for larger version

Name:	81Htb+HPm0L._AC_SL1500_.jpg
Views:	45
Size:	61.2 KB
ID:	97417
syjos is offline   Reply With Quote
Old 12-10-2019, 12:14 PM   #18
Guru

Russell Clifton's Avatar

City: La Conner Wa.
Country: usa
Vessel Name: Sea Fever
Vessel Model: Defever 49 RPH
Join Date: Sep 2012
Posts: 625
If the pressure in the accumulator is not correct it will cause this problem. I have had this problem in the past, corrected the pressure, solved problem. Research what the pressure should be, check it with a tire gauge. Easy to do.
Russell Clifton is offline   Reply With Quote
Old 12-10-2019, 04:53 PM   #19
Member

City: Marina del Rey
Country: United States
Vessel Name: Fortunate Son
Vessel Model: 42' Grand Banks M/Y
Join Date: Feb 2017
Posts: 22
Thanks

Hi Everyone,

THANK YOU for all your suggestions. Greg, the pressure does not change and the pulses do have a consistent rhythm. I would guess the pulses to be two to three seconds in duration.

Thanks again everyone and Happy Holidays.

Lucky
R lucky is offline   Reply With Quote
Old 12-16-2019, 03:41 PM   #20
Senior Member

City: Russell NZ
Country: Russell NZ
Vessel Name: MV Unique
Vessel Model: Salthouse Coastal 35
Join Date: Jul 2013
Posts: 121
We had exact same problem turned out to be incorrect pressure at our accumulator tank for what it's worth
__________________

Phil23 is offline   Reply With Quote
