New Teak...Face?

Greetings,

After a busy summer of work and boating, I decided to launch into yet another wood project on the boat this fall. Winter has shut down progress for now but thought I would post some pics.

I don't know the correct nomenclature of the teak "face" I'm replacing but its the flat, 2-1/4" wide section that is framed on top by the rail cap and a matching lower bullnose. From the pic you can see that the original wood was pretty far gone: checks/splits, screw heads pulled through, paper thin plug faces.

Based on its condition I decided to remove it a year and a half ago while refinishing the rail cap to allow access to clean and finish all the way under the bullnose. The plan was to save it as a template....it came up in 10-15" pieces. The only useful pieces were the corner miter joints.

I had plenty of Qtr sawn Afromosia left over from replacing the FB rail cap so the main quandary was how to attach the new wood. Countersinking a few hundred screws into 3/8" thick material and then covering with bungs didn't make sense so I opted to use epoxy.

Templates were made from door skin material and the patters roughed out on a band saw. The top and bottom edges were chamfered to minimize the sanding required. Once sanded to fit, each piece received two coats of laminating epoxy and was block sanded smooth.

A large forstner bit was used to bore out a clean bonding point for the epoxy about every 6". I elected to use Total Boat "FlexEpox" thickened with silica.

I'm pleased with the results so far. I was able to get 2/3 of the port side applied and sealed with 2 coats of varnish before the daily temps dropped.
Attached Thumbnails
Click image for larger version

Name:	Starting Point.jpg
Views:	181
Size:	134.2 KB
ID:	60170   Click image for larger version

Name:	Template (2).jpg
Views:	179
Size:	23.0 KB
ID:	60171   Click image for larger version

Name:	Clamps.jpg
Views:	178
Size:	192.9 KB
ID:	60173
Attached Images

__________________
Advertisement

__________________
Eric

Please throw me the bowline Fraulein!
Aft Deck Capt is offline   Reply With Quote
Old 01-06-2017, 06:55 AM   #2
Enigma

RT Firefly's Avatar

City: Slicker?
Country: Bumpkin?
Join Date: Oct 2007
Posts: 12,629
Greetings,
Mr. ADC. Impressive!
__________________

__________________
RTF
RT Firefly is online now   Reply With Quote
Old 01-06-2017, 08:40 AM   #3
Guru

City: Hotel, CA
Country: Fried
Join Date: Sep 2011
Posts: 8,324
Excellent job! Looking nice!
__________________
Craig

It's easier to fool people than to convince them that they've been fooled - Mark Twain
CPseudonym is offline   Reply With Quote
Old 01-06-2017, 08:48 AM   #4
Guru

Bob Cofer's Avatar

City: Caimanera
Country: Cuba
Vessel Name: Seafarer
Vessel Model: 1926 56 Winslow RDMY
Join Date: Aug 2013
Posts: 1,182
Nice work!
__________________
What kind of boat is that?
Bob Cofer is offline   Reply With Quote
Old 01-06-2017, 08:52 AM   #5
Guru

MurrayM's Avatar

City: Kitimat, North Coast BC
Country: Canada
Vessel Name: Badger
Vessel Model: 30' Sundowner Tug
Join Date: Jul 2012
Posts: 4,763
Conformation that one cannot have too many vices...I mean vises
__________________
"The most interesting path between two points is not a straight line" Murray Minchin
MurrayM is offline   Reply With Quote
Old 01-06-2017, 08:54 AM   #6
TF Site Team

dimer2's Avatar

City: Cameron, La
Country: USA
Vessel Name: Baobab
Vessel Model: Bayliner 4788
Join Date: Aug 2013
Posts: 2,655
Beautiful!
dimer2 is offline   Reply With Quote
Old 01-06-2017, 11:18 AM   #7
Guru

DHeckrotte's Avatar

City: Philadelphia, PA
Country: USA
Vessel Name: Revel
Vessel Model: 1984 Fu Hwa 39
Join Date: Nov 2015
Posts: 999
Beautiful work!

And, you really cannot have too many clamps. I've even had to make special-purpose clamps and clamping jigs. (Note the wood-blocks-and-drywall screw clamps on the left.) Push sticks or wedges are good, too, if you have a place against which to push. (The push-against place has to be stiff or it's pretty annoying; the jig I made for laminating the FD stem was tied down and hung in the centerboard trunk; back and forth tightening wedges.) I've even used Spanish windlasses.
Attached Thumbnails
Click image for larger version

Name:	2015-06-07 BackPorch Crane 002.jpg
Views:	82
Size:	141.3 KB
ID:	60187   Click image for larger version

Name:	AA_1807_025.jpg
Views:	86
Size:	125.5 KB
ID:	60188
DHeckrotte is offline   Reply With Quote
Old 01-06-2017, 01:13 PM   #8
Guru

Xsbank's Avatar

City: Pender Harbour, BC
Country: Canada
Vessel Name: Gwaii Haanas
Vessel Model: Vancouver Shipyards Custom Aluminum 52
Join Date: Sep 2013
Posts: 3,213
You really should have bought a wooden boat, your talents are not fully exploited by a plastic boat. Very nice indeed. Your patience is what I lack to ever have wood on the outside again.

Actually, I'm overwhelmed. That is magnificent work, I think I need to go and lie down.
__________________
Don't believe everything that you think.
What are we offended about today?
Xsbank is offline   Reply With Quote
Old 01-06-2017, 02:43 PM   #9
TG
Senior Member

TG's Avatar

City: Oceanside, CA
Country: USA
Vessel Name: Tera Grace
Vessel Model: Californian 42 LRC
Join Date: Oct 2012
Posts: 173
I'm surprised there's no gelcoat under there or did you grind it off?
TG is offline   Reply With Quote
Old 01-06-2017, 03:44 PM   #10
Guru

Lou_tribal's Avatar

City: Quebec
Country: Canada
Vessel Name: Bleuvet
Vessel Model: Custom Built
Join Date: Jan 2016
Posts: 3,490
I also have a teak face



Special dedication to Mr RTF
Lou_tribal is online now   Reply With Quote
Old 01-11-2017, 12:36 AM   #11
Senior Member

Aft Deck Capt's Avatar

City: Tri-Cities WA
Country: US
Vessel Name: Long Shot
Vessel Model: 1978 Californian 42' LRC
Join Date: May 2014
Posts: 168
TG, it's odd. There is gelcoat from the stern forward to where the rail cap turns up to the flat section that continues to the bow. From there, the FG is bare.

I performed an adhesion test on both sections and could tell that there was still enough release agent on the surfaces to compromise the bonding. That was part of the motivation to bore into fresh material along with minimizing the squeeze out.
__________________
Eric

Please throw me the bowline Fraulein!
Aft Deck Capt is offline   Reply With Quote
Old 01-11-2017, 08:18 AM   #12
TF Site Team

Pack Mule's Avatar

City: Paris,TN
Country: USA
Vessel Name: William
Vessel Model: Outer reef 32
Join Date: Jan 2013
Posts: 3,360
Very nice job . Love the quarter sawn . Here are some oak faces .
Attached Thumbnails
Click image for larger version

Name:	IMG_2465.jpg
Views:	67
Size:	132.8 KB
ID:	60328
Pack Mule is offline   Reply With Quote
Old 01-11-2017, 08:24 AM   #13
TF Site Team

Pack Mule's Avatar

City: Paris,TN
Country: USA
Vessel Name: William
Vessel Model: Outer reef 32
Join Date: Jan 2013
Posts: 3,360
And a walnut face . When the grand kids were little they wouldn't sit at this end of the table because of the "wolf ". I never noticed it till they pointed it out.
Attached Thumbnails
Click image for larger version

Name:	IMG_2466.jpg
Views:	67
Size:	126.9 KB
ID:	60329
Pack Mule is offline   Reply With Quote
Old 01-22-2017, 01:48 PM   #14
Member

City: Kodiak
Country: United States
Vessel Name: Nautical Girl
Vessel Model: Wellcraft California 34 LRC
Join Date: Jun 2012
Posts: 19
Outstanding

What type of Varnish? I have tried a few, and none hold up after a Alaska winter.
Mu teak is bare now, thinking of oil..
Capt Q is offline   Reply With Quote
Old 01-22-2017, 02:33 PM   #15
TF Site Team

FlyWright's Avatar

City: California Delta and SF Bay
Country: Sacramento, CA, USA (boat in Vallejo)
Vessel Name: FlyWright
Vessel Model: Marshall Californian 34 LRC
Join Date: Apr 2008
Posts: 12,300
Very interesting and nice work! My 1977 34 doesn't have that style of 'face' as shown in this shot with my rub rail removed last year. With the rubrail off, the hull-cap joint is revealed.

__________________
My boat is my ark. It's my mobile treehouse and my floating fishing cabin. It's my retreat and my respite. Everyday I thank God I have a boat! -Al

@DeltaBridges - 25 Delta Bridges in 25 Days
FlyWright is offline   Reply With Quote
Old 01-22-2017, 03:00 PM   #16
omc
Senior Member

omc's Avatar

City: South
Country: France
Vessel Name: LUTIN
Vessel Model: Grand Banks 42' Motor Yacht
Join Date: Sep 2015
Posts: 481
Quote:
Originally Posted by FlyWright View Post
Very interesting and nice work! My 1977 34 doesn't have that style of 'face' as shown in this shot with my rub rail removed last year. With the rubrail off, the hull-cap joint is revealed.
Very nice boat Al, and I love the design of the hull.
__________________
Olivier
omc is offline   Reply With Quote
Old 01-22-2017, 05:16 PM   #17
Senior Member

Aft Deck Capt's Avatar

City: Tri-Cities WA
Country: US
Vessel Name: Long Shot
Vessel Model: 1978 Californian 42' LRC
Join Date: May 2014
Posts: 168
Quote:
Originally Posted by Capt Q View Post
What type of Varnish? I have tried a few, and none hold up after a Alaska winter.
Mu teak is bare now, thinking of oil..
I'm using System Three gloss spar over S3 laminating epoxy on the face. I think the key to making the finish last is keeping the moisture from getting under the varnish, hence two coats of epoxy as a base. I've used this layup on all of the teak that has been refinished or replace so far.

As a test (partially driven by time constraints), the lower bullnose received 4 coats of McLosky's satin spar varnish without any epoxy under coat. This varnish has a very high oil content, brushes out nicely and seems to stay very flexible after drying. It will be interesting to see how it lasts compared to the other layup.

We're exposed to the elements 24/7. The teak finished with the epoxy+ varnish nearly two years ago has started to show hazing of the gloss varnish but no peeling. So...the cap rail and toe rail will get a scuff and recoat this spring/summer. Just in time!...I was running out of things to do on the boat.
__________________
Eric

Please throw me the bowline Fraulein!
Aft Deck Capt is offline   Reply With Quote
Old 01-23-2017, 07:11 AM   #18
Senior Member

City: South East
Country: France
Join Date: Aug 2016
Posts: 473
Quote:
Originally Posted by Lou_tribal View Post
I also have a teak face
You have a teak face, your wife is a leopard... Strange things begin to happen in Quebec province
__________________

__________________
P.
